Specification Summary
- Cat C2.4 TurboNet Power46.8 hpBore87 mmDisplacement2.43 l
Additional Information
Engine
| Engine Model | Cat C2.4 Turbo |
| Net Power | 46.8 hp |
| Bore | 87 mm |
| Displacement | 2.43 l |
| Gross Power - ISO 14396 | 48.9 hp |
| Rated Net Power - 2,400 rpm - ISO 9249/EEC 80/1269 | 46.8 hp |
| Stroke | 102 mm |
| Note | Meets China Nonroad Stage IV emission standard. |
| Note (1) | Advertised power is tested per the specified standard in effect at the time of manufacture. |
| Note (2) | Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system, and alternator. |
Weights
| Operating Weight | 6175 kg |
| Operating Weight - With Cab | 6175 kg |
| Note | Weight is based on steel tracks, operator, full fuel tank, standard stick and bucket. |
Travel System
| Travel Speed - High | 5 km/h |
| Travel Speed - Low | 3.1 km/h |
| Maximum Traction Force - High Speed | 31 kN |
| Maximum Traction Force - Low Speed | 51 kN |
| Ground Pressure | 33.7 kPa |
| Gradeability - Maximum | 30 degrees |
Service Refill Capacities
| Cooling System | 10 l |
| Engine Oil | 9.5 l |
| Fuel Tank | 105 l |
| Hydraulic System | 104 l |
| Hydraulic Tank | 53 l |
Hydraulic System
| Pump Flow at 2,400 rpm | 151 l/min |
| Operating Pressure - Equipment | 252 bar |
| Operating Pressure - Travel | 252 bar |
| Operating Pressure - Swing | 210 bar |
| Auxiliary Circuit - Primary - Flow | 98 l/min |
| Auxiliary Circuit - Primary - Pressure | 186 bar |
Swing System
| Machine Swing Speed | 11.3 r/min |
Blade
| Width | 1980 mm |
| Height | 375 mm |
Certification - Cab
| Roll Over Protective Structure (ROPS) | ISO 12117-2:2008 |
| Top Guard | (Optional) ISO 10262:1998 (Level I) |
Dimensions - Standard Stick
| Boom In Reach | 2126 mm |
| Cab Height | 2540 mm |
| Dig Depth | 3902 mm |
| Ground Clearance | 306 mm |
| Maximum Blade Depth | 615 mm |
| Maximum Blade Height | 420 mm |
| Maximum Dig Height | 5490 mm |
| Maximum Dump Clearance | 3870 mm |
| Maximum Reach | 6090 mm |
| Maximum Reach - Ground Level | 5975 mm |
| O/A Shipping Length | 5789 mm |
| O/A Track Width | 1980 mm |
| O/A Undercarriage Length | 2532 mm |
| Stick Length | 1650 mm |
| Swing Bearing - Height | 657 mm |
| Tail Swing | 1585 mm |
| Track Belt/Shoe Width | 400 mm |
| Transport Height | 2206 mm |
| Vertical Wall | 2414 mm |
| Width over Upper House | 1950 mm |
Sound
| Operator Sound Pressure (ISO 6396:2008) | 72 dB(A) |
