Additional Information

Engine Model	Cat® C18 Diesel Engine with ACERT™ Technology
Bore	145 mm
Stroke	183 mm
Displacement	18.1 l
Net Power - 1,800 rpm - 80/1269/EEC	530 HP
Net Power - ISO 14396	537 HP
Net Power - 1,800 rpm - ISO 9249	530 HP
Gross Power - SAE J1995	553 HP

Swing Speed	6.4 rpm
Swing Torque	260 kN·m

Track Width - Standard	650 mm
Track Width - Optional	750 mm
Number of Shoes - Each Side	47
Number of Carrier Rollers - Each Side	3
Number of Track Rollers - Each Side	8

Fuel Tank	1240 l
Cooling System	101 l
Engine Oil	65 l
Final Drive - Each	21 l
Hydraulic System - Including Tank	995 l
Hydraulic Tank	810 l
Swing Drive - Each	19 l

Operating Weight - With 5.7 m3 Rock Bucket, 650 mm Shoes

90600 kg

Maximum Drawbar Pull	592 kN
Maximum Travel Speed	4.5 km/h

Cylinders - Stick - Bore	220 mm
Pilot - Relief Valve Setting - Controls	41 bar
Cylinders - Master - Bore	152 mm
Main/Travel - Number of Main Pumps	2
Main/Travel - Relief Valve Setting - Main	320 bar
Cylinders - Master - Stroke	1953 mm
Cylinders - Bucket - Bore	178 mm
Cylinders - Boom - Stroke	1415 mm
Pilot - Circuit	Open center
Pilot - Maximum Flow at Rated Speed	90 l/min
Cylinders - Bottom Dump - Stroke	275 mm
Swing - Maximum Flow at Rated Speed (Total)	450 l/min
Cylinders - Bottom Dump - Bore	160 mm
Main/Travel - Maximum Flow at Rated Speed	2 × 490 L/min
Pilot Pump	Gear
Main/Travel - Pump	Piston, variable
Swing - Number of Swing Pumps	1
Cylinders - Stick - Stroke	1855 mm
Swing - Relief Valve Setting - Accelerating	260 bar
Main/Travel - Relief Valve Setting - Travel	350 bar
Swing Pump	Piston, variable
Swing Circuit	Open center, load sensing
Cylinders - Bucket - Stroke	1810 mm
Pilot - Number of Pilot Pumps	1
Cylinders - Boom - Bore	180 mm
Main/Travel - Circuit	Closed center, load sensing

Standards

Exterior Sound	Standards
Operator Sound	Standards
