Specification Summary
- Power - Net89 hpOperating Weight - Nominal8425 kgOperating Weight - Maximum11000 kgModelCat 3054C Mechanical Turbo
Additional Information
| Power - Net | 89 hp |
| Model | Cat 3054C Mechanical Turbo |
| Emissions | Engine meets U.S. EPA Tier 2/EU Stage II equivalent emission standards. |
| Rated Power (Standard) - 2,200 rpm - Gross - ISO 14396 | 93 hp |
| Net Peak Power Rating @ 2,200 rpm - SAE J1349 | 66.4 |
| Torque Rise - 1,200 rpm - Net | 38 |
| Maximum Torque - 1,400 rpm | 394 N·m |
| Bore | 105 mm |
| Stroke | 127 mm |
Weights
| Operating Weight - Nominal | 8425 kg |
| Operating Weight - Maximum | 11000 kg |
| Operating Weight | 8425 kg |
Hydraulic System
| Type | Closed Center |
| Pump Type | Variable Flow, Axial Piston |
| Maximum Pump Capacity | 132 l/min |
| System Pressure - Backhoe | 250 bar |
| System Pressure - Loader | 250 bar |
Noise Level
| Inside Cab | 80 dB(A) |
| Outside Cab | 104 dB(A) |
Transmission
| Note | Travel speeds of Four Wheel Drive backhoe loader at full throttle, when equipped with 16.9×28 rear tires. |
| Power Shuttle Transmission - Forward 1st | 5.6 km/h |
| Power Shuttle Transmission - Forward 2nd | 9.3 km/h |
| Power Shuttle Transmission - Forward 3rd | 21 km/h |
| Power Shuttle Transmission - Forward 4th | 40 km/h |
| Power Shuttle Transmission - Reverse 1st | 5.6 km/h |
| Power Shuttle Transmission - Reverse 2nd | 9.3 km/h |
| Power Shuttle Transmission - Reverse 3rd | 21 km/h |
| Power Shuttle Transmission - Reverse 4th | 40 km/h |
Service Refill Capacities
| Cooling System | 22 l |
| Fuel Tank | 160 l |
| Engine Oil - With Filter | 8.8 l |
| Transmission - Power Shuttle - AWD | 15 l |
| Rear Axle | 16.5 l |
| Rear Axle - Planetaries | 1.7 l |
| Front Axle (AWD) | 6.5 l |
| Front Axle (AWD) - Planetaries | 0.7 l |
| Hydraulic System | 106 l |
| Hydraulic Tank | 40 l |
Weights*
| Operating Weight - Estimated | 8425 kg |
| Operating Weight - ROPS Capacity - Maximum | 11000 kg |
| Counterweights - Base | 115 kg |
| Counterweights - Medium | 240 kg |
| Note | *Machine Configuration – standard engine, standard stick hoe, standard cab with A/C, AWD standard shift transmission, 0.96 m3 MP loader bucket, 24 inch standard duty hoe bucket, 12.5/80-18 and 16.9-28 tires, no counterweight, 80 kg operator and full fuel tank. |
| Minimum Counterweight Recommendations - E-Stick: E-Stick | 210 kg |
| Minimum Counterweight Recommendations - E-Stick: Loader Bucket - MP with Fork Brackets | 691 kg |
| Minimum Counterweight Recommendations - E-Stick: Loader Bucket - GP | 530 kg |
| Minimum Counterweight Recommendations - E-Stick: Loader Bucket - MP | 681 kg |
| Counterweights - High | 460 kg |
Axles - All Wheel Drive (AWD)
| Features (1) | Heavy-duty rear axle with self adjusting inboard brakes and final drives. |
| Features (2) | AWD is engaged by front console panel switch or by brake pedal during all-wheel-braking operation. AWD can be engaged on the move, under load, in any gear, forward or reverse. AWD has outer final drives for easy maintenance. |
| Features (3) | AWD front axle is pendulum mounted and permanently sealed and lubricated, requiring no daily maintenance. Also features double-acting steering cylinder with 52° steering angle for increased maneuverability. |
Axle Ratings
| Front Axle (AWD) - Static | 22964 kg |
| Front Axle (AWD) - Dynamic | 9186 kg |
| Rear Axle - Static | 22964 kg |
| Rear Axle - Dynamic | 9186 kg |
Steering
| Type | Front Wheel |
| Power Steering | Hydrostatic |
| AWD Cylinder, One (1) Double Acting - Bore | 65 mm |
| AWD Cylinder, One (1) Double Acting - Stroke | 120 mm |
| AWD Cylinder, One (1) Double Acting - Rod Diameter | 36 mm |
| Turning Circle - AWD (inner wheel not braked) - Outside, Front Wheels | 8.18 m |
| Turning Circle - AWD (inner wheel not braked) - Outside, Widest Loading Bucket | 10.97 m |
Brakes
| Type | Fully enclosed boosted, hydraulic, multiple discs. |
| Features (1) | Inboard oil-immersed, hydraulically actuated multiple Kevlar discs on final drive input shaft. |
| Features (2) | Completely enclosed and sealed. |
| Features (3) | Self-adjusting. |
| Features (4) | Dual foot-operated boosted brake pedals can be interlocked for roading. |
| Features (5) | Parking/secondary brakes are independent of the service brake system. Parking (secondary) brake is mechanically applied through a hand lever located in the right side console. |
| Features (6) | Meets ISO 3450:2011 and CMVR requirements. |
Excavator Bucket Dimensions and Performance: Standard Stick
| Bucket Dig Force | 57.22 kN |
| Digging Depth, Manufacturer's Maximum | 4707 mm |
| Loading Reach | 1528 mm |
| Maximum Operating Height | 5721 mm |
| Stick Dig Force | 35.3 kN |
| Digging Depth, 2440 mm Flat Bottom | 3740 mm |
| Reach from Swing Pivot at Ground Line | 5603 mm |
| Digging Depth, 600 mm Flat Bottom, Manufacturer's | 4668 mm |
| Bucket Rotation | 205° |
| Stabilizer Overall Width | 2242 mm |
| Digging Depth, 600 mm Flat Bottom | 4092 mm |
| Digging Depth, SAE Maximum | 4116 mm |
| Loading Height | 3934 mm |
| Swing Arc | 180° |
Loader Bucket Dimensions and Performance: MP - 1 m3
| Maximum Operating Height | 4348 mm |
| Tilt Breakout Force | 60.47 kN |
| Dump Height at Maximum Angle | 2766 mm |
| Tipping Load at Breakout Point | 6301 kg |
| Maximum Hinge Pin Height | 3449 mm |
| Lift Breakout Force | 53.95 kN |
| Maximum Bucket Rollback at Ground Level | 42° |
| Grill to Bucket Cutting Edge, Carry Position | 1449 mm |
| Width | 2262 mm |
| Dump Reach at Maximum Angle | 822 mm |
| Digging Depth | 145 mm |
| Lift Capacity at Maximum Height | 3496 kg |
| Maximum Grading Angle | 116° |
| Dump Angle at Full Height | 46° |
| Capacity | 1 m³ |
Excavator Bucket Dimensions and Performance: E-Stick Extended
| Stabilizer Overall Width | 2242 mm |
| Maximum Operating Height | 6338 mm |
| Loading Reach | 2546 mm |
| Stick Dig Force | 24.59 kN |
| Swing Arc | 180° |
| Loading Height | 4491 mm |
| Digging Depth, SAE Maximum | 5208 mm |
| Reach from Swing Pivot at Ground Line | 6585 mm |
| Digging Depth, Manufacturer's Maximum | 5697 mm |
| Digging Depth, 2440 mm Flat Bottom | 4887 mm |
| Digging Depth, 600 mm Flat Bottom, Manufacturer's | 5684 mm |
| Bucket Dig Force | 56.61 kN |
| Bucket Rotation | 205° |
| Digging Depth, 600 mm Flat Bottom | 5168 mm |
Loader Bucket Dimensions and Performance: MP with Forks - 1 m3
| Maximum Operating Height | 4832 mm |
| Dump Reach at Maximum Angle | 822 mm |
| Digging Depth | 145 mm |
| Tilt Breakout Force | 59.26 kN |
| Lift Capacity at Maximum Height | 3172 kg |
| Tipping Load at Breakout Point | 6048 kg |
| Maximum Hinge Pin Height | 3449 mm |
| Lift Breakout Force | 51.04 kN |
| Dump Height at Maximum Angle | 2766 mm |
| Capacity | 1 m³ |
| Width | 2262 mm |
| Maximum Bucket Rollback at Ground Level | 40° |
| Dump Angle at Full Height | 46 ° |
| Grill to Bucket Cutting Edge, Carry Position | 1449 mm |
| Maximum Grading Angle | 116° |
Excavator Bucket Dimensions and Performance: E-Stick Retracted
| Digging Depth, 2440 mm Flat Bottom | 3806 mm |
| Loading Reach | 1648 mm |
| Reach from Swing Pivot at Ground Line | 5657 mm |
| Digging Depth, 600 mm Flat Bottom | 4158 mm |
| Loading Height | 3947 mm |
| Maximum Operating Height | 5722 mm |
| Bucket Dig Force | 56.61 kN |
| Stabilizer Overall Width | 2242 mm |
| Digging Depth, Manufacturer's Maximum | 4756 mm |
| Stick Dig Force | 33.66 kN |
| Digging Depth, 600 mm Flat Bottom, Manufacturer's | 4719 mm |
| Digging Depth, SAE Maximum | 4191 mm |
| Swing Arc | 180° |
| Bucket Rotation | 205° |
Backhoe Digging Depth
| Dig Depth | 4707 mm |
| E-Stick Extended | 5697 mm |
| E-Stick Retracted | 4756 mm |
Loader Bucket Dimensions and Performance: GP - 1.05 m3
| Capacity | 1.05 m³ |
| Width | 2262 mm |
| Lift Capacity at Maximum Height | 3610 kg |
| Lift Breakout Force | 54.48 kN |
| Tilt Breakout Force | 53.91 kN |
| Tipping Load - Breakout Point | 6225 kg |
| Maximum Hinge Pin Height | 3449 mm |
| Dump Angle at Full Height | 46° |
| Dump Height at Maximum Angle | 2735 mm |
| Dump Reach at Maximum Angle | 897 mm |
| Maximum Bucket Rollback at Ground Level | 41° |
| Digging Depth | 112 mm |
| Maximum Grading Angle | 113° |
| Grill to Bucket Cutting Edge, Carry Position | 1480 mm |
| Maximum Operating Height | 4370 mm |
Loader Bucket Dimensions and Performance: MP - 1.0 m3
| Capacity | 0.96 m³ |
| Width | 2262 mm |
| Lift Capacity at Maximum Height | 3475 kg |
| Lift Breakout Force | 54 kN |
| Tilt Breakout Force | 60.48 kN |
| Tipping Load - Breakout Point | 7110 kg |
| Maximum Hinge Pin Height | 3447 mm |
Machine Dimensions - 426 Phase 2: GP - 1.05 m3
| Overall Length in Roading Position | 225 in |
| Overall Transportation Length | 5677 mm |
| Overall Transportation Height - 4.3 m | 3757 mm |
| Overall Width | 2346 mm |
| Height to Top of Cab/Canopy | 2895 mm |
| Height to Top of Exhaust Stack | 2716 mm |
| Rear Axle Centerline to Front Grill | 2708 mm |
| Wheelbase AWD | 2200 mm |
Machine Dimensions - 426 Phase 2: MP - 1 m3
| Overall Length in Roading Position | 5674 mm |
| Overall Transportation Length | 5681 mm |
| Overall Transportation Height - 4.3 m | 3757 mm |
| Overall Width | 2346 mm |
| Height to Top of Cab/Canopy | 2895 mm |
| Height to Top of Exhaust Stack | 2716 mm |
| Rear Axle Centerline to Front Grill | 2708 mm |
| Wheelbase AWD | 2200 mm |
| Note | Dimensions and performance specifications shown are for machines equipped with 12.5/80-18 front tires, 16.9-28 rear tires, standard cab, standard stick with 610 mm standard duty bucket, and standard equipment unless otherwise specified. |
